Drivers	HF:2×1.4"Voice-coil:3" MF:4×6.5"Voice-coil:1.46" LF:2×12"Voice-coil:3"
Frequency (-10dB)	40-18000Hz
Dispersion(-6dB)	H 120° x V8°
Sensitivity（1m/1W)	HF:109dB MF:106.5dB LF:102.5dB
Maximum SPL	134.5dB continuous /140.5dB Peak
Standard impedance	HF:8 Ohms MF:8 Ohms LF:2x8 Ohms
Rated Power	HF:2X180W RMS/720W Peak MF:4X180W RMS /1440w Peak LF:2x800W RMS/3200W Peak
Crossover Frequency	210Hz-1880Hz
Power amp	300W/8 Ohms+800W/8 Ohms+1600W/4 Ohms
Amplifier type	Switched power amplifier, Class D circuit, with DSP/96K processing
Connectors	2×Speakon XLR
Material	High-quality double-layer birch plywood box
Mesh surface	High-strength steel mesh with hexagonal holes and special sound-transmitting sponge mesh inside.
Finish	Environmental protection water-based paint
Handing Position	Dedicated hoisting system
Dimensions(H×WxD)	367mm×970mm×639mm
Net Weight(Kg)	60.6

Constrction DraWing:
