Drivers	HF:2×1"Voice-coil:1.75" LF:1×10"Voice-coil:2.5"
Frequency (-10dB)	70-18000Hz
Dispersion(-6dB)	horizontal: 80°Splay angle setting:0°-12°
Sensitivity（1m/1W)	HF:105dB/LF:97dB
maximum SPL	124.6dB Continuous /130.6dB Peak
Nominal Impedance	HF:16 Ohms/LF:8 Ohms
Rated Power	HF: 140W RMS/280W Peak ; LF: 580W RMS /1160W Peak
Crossover Frequency	1800 Hz
Connectors	2x Speakon NL4MP
Material	High-quality double-layer birch plywood box
Mesh surface	High-strength steel mesh with hexagonal holes and special sound-transmitting sponge mesh inside.
Finish	Environmental protection water-based paint
Handing Position	Dedicated hoisting system
Dimensions(H×WxD)	298mm×530mm×420mm
Net Weight(Kg)	19.4

MODEL:LA-118A

Drivers	LF:1×18"Voice-coil:4"
Frequency(-10dB)	35-180Hz
Dispersion(-6dB)	--------
Sensitivity（1m/1W)	100dB/（1W/1M）
maximum SPL	130.6dB Continuous / 136.6dB Peak
Nominal Impedance	8 Ohms
Rated Power	1160W RMS / 2320W Peak
Power amp	300W/8 Ohms+1200W/4 Ohms+1000W/8 Ohms
Amplifier type	Switched power amplifier, Class D circuit, with DSP/96K processing
Connectors	2x Speakon XLR
Material	High-quality double-layer birch plywood box
Finish	Environmental protection water-based paint
Dimensions(H×WxD)	600mm×950mm×650mm
Net Weight(Kg)	56
