Applications：
High-end fixed installation places such as large bars, party night venues, theaters, multi-function halls, auditoriums, etc.
Engineering Information：
MODEL: MC-15
Drivers | HF:1×1.4"Voice-coil:3"/LF:1×15"Voice-coil:3" |
Frequency(-10dB) | 45-18000Hz |
Dispersion(-6dB) | 80°×60° |
Sensitivity(1m/1w) |
102dB |
Maximum SPL | 131.8dB Continuous/137.8dB Peak |
Nominal Impedance | 8 Ohms |
Rated Power | 960W RMS/1920W Peak |
| Crossover Frequency： | 1500Hz
|
| Material | High-quality double-layer birch plywood box |
Mesh surface |
High strength hexagonal perforated steel mesh with special acoustic sponge mesh. |
Finish | Environmental protection water-based paint |
Connectors | 2×Speakon NL4MP |
Handing Position | 12 M8Lifting point
|
| Dimexnsions(H×W×D) | 600mm x 425mm x 405mm |
| Net Weight(Kg) | 26.9
|
Constrction DraWing:
