Applications：
High-end fixed installation places such as large bars, party night venues, theaters, multi-function halls, auditoriums, etc.
Engineering Information：
MODEL: MC-12
Drivers | HF:1×1"Voice-coil:1.73"/LF:1×12"Voice-coil:2.5" |
Frequency(+/-3dB) | 50-18000Hz |
Dispersion(-6dB) | 80° - 60° |
Sensitivity(1m/1w) |
99dB |
Maximum SPL | 128dB Continuous/134dB Peak |
Nominal Impedance | 8 Ohms |
Rated Power | 800W RMS/1600W Peak |
| Crossover Frequency | 2000Hz |
| Material | High-quality double-layer birch plywood box |
Mesh surface | High strength hexagonal perforated steel mesh with special acoustic sponge mesh |
Finish | Environmental protection water-based paint |
Connectors | 2×Speakon NL4MP |
Handing Position | 12 M8Lifting point
|
| Dimexnsions(H×W×D) | 500mm×380mm×360mm |
| Net Weight(Kg) | 18
|
Constrction DraWing:
