Applications:
Applicable places: performances, performing arts bars, party bars, music restaurants, auditoriums.
Engineering Information:
MODEL:TQ-2210
Drivers | HF:1×1.4"Voice-coil:3" LF:2×10"Voice-coil:2.5" |
Frequency (-10dB) | 68-18000Hz |
Dispersion(-6dB) | horizontal:80°-100°/Splay angle setting:0°-12°(1°increment) |
Sensitivity(1m/1W) | HF:103dB/LF:98dB |
Maximum SPL | 128.7dB continuous/134.7dB Peak |
Nominal Impedance | HF:8 Ohms/LF:8 Ohms |
Rated Power | HF:140W RMS/280W Peak LF:1180W RMS /2360WPeak |
Recommended AMP | HF:200W/8 Ohms LF:1300W/8 Ohms |
Crossover Frequency | 1200Hz |
Connectors | 2x Speakon NL4MP |
Material | High-quality double-layer birch plywood box |
Mesh surface | High-strength steel mesh with hexagonal holes and special sound-transmitting sponge mesh inside. |
Finish | Environmental protection water-based paint |
Handing Position | Dedicated hoisting system |
Dimensions(H×WxD) | 290mm×700mm×516mm |
Net Weight(Kg) | 29.5 |
Constrction DraWing:
