Applications：
K film system, top entertainment clubs, nightclubs, high-end mass-market KTV, music bars, auditoriums, meeting rooms and other places.
Engineering Information：
MODEL: KC-1210
| Drivers | LF:1×12"Voice-coil:3"
|
| Frequency(-10dB) | 40-250Hz |
| Dispersion(-6dB) | ------- |
| Sensitivity(1m/1w) | 97dB |
| Maximum SPL | 124.6dB Continuous/130.6dB Peak |
| Nominal Impedance | 8 Ohms |
| Rated Power | 580W RMS/1160W Peak |
| Recommended AMP | 600W/8 Ohms |
| Material | High-quality double-layer birch plywood box |
| Mesh surface | High-strength pressed hexagonal mesh surface, with grey acoustic transparent guitar mesh attached to the outside |
| Finish | Environmental protection water-based paint |
| Connectors | 2×Speakon NL4MP |
| Dimexnsions(H×W×D) | 370mm×(370)mm×506mm |
| Net Weight(Kg) | 17.3 |
Constrction DraWing:
